Powering The Space Race

, , , , , ,

After several weeks of Covid-19 shutdown, many businesses are coming out of quarantine and negotiating a plan for getting back to work quickly and safely – without skipping a beat on productivity.

THE NEW SPACE RACE

It’s what we’re calling the rush to critically re-evaluate office terrain. Assessing how environments are currently being used and how might those spaces be re-imagined in this “new normal.”

Just like the original Space Race – it’s a competition to see who can win by being the fastest to firsts in a whole new age. Only this time, it’s about being the first to figure out how to reconfigure the workspace to incorporate physical distancing.

Whenever we are racing to make huge leaps and giant changes to our everyday lives, technology is at the forefront. Good old Technology – the true VIP of social distancing. Video calls, ordering groceries online, ordering everything online, working from home; It’s all made possible by technology. And this huge increase in working-from-home isn’t going away once stay-at-home orders are lifted. In fact, Global Workplace Analytics estimates that 25-30% of the workforce will be working-from-home multiple days a week by end of 2021.

Even with a larger number of employees handling business from home, about 75% of employees will be returning to work in a shared workplace. And, finding a way to bring them back in safely is a huge undertaking. This one can’t be solved with Zoom Meetings and online shopping. For these changes, we must get back to physical space.

Currently, the CDC recommends we give each employee 6 ft. of space and we know that’s the number one factor when it comes to re-configuring the workplace. It’s a game changer. The open office floor plan was designed around the idea of fitting as many people as possible in a collaborative work environment. Now we have to completely flip the switch – without sacrificing the connectedness of the open floor plan we’ve grown to love. And we have to do it fast. Byrne’s own Facility Manager, Dane, is dealing with this challenge right now.

“Real Estate is a hard thing to come by, so maximizing spaces to their full dimensions is critical. Getting more out of our physical space while creating an inviting and safe place to work is the ultimate goal.”

Needless to say, he’s been busy. Hard at work; researching and implementing creative solutions for maximizing space and encouraging safe, social distancing.

We’ve compiled a list of some quick-fix office reconfig ideas that can help you make the most of your space as employees start to return to the work place.

RE-CONFIGURING TIPS FOR SOCIAL DISTANCING IN THE OFFICE


From “we” to “me.”















Modifying Collaborative Space to work as Dedicated Space
Reclaim work cafés and walk-up meeting areas to create more permanent work spaces. Office design over the last decade has shifted to more common areas – more choice in where you can work. Because of that, these collaborative spaces often have more square footage in the floor plan than designated desking. Think of it as “we” space to compensate for less “me” space. For social  distancing, reclaiming some of this shared space is key.

Divide to unite.

Adding Space Dividers to Create Physical Barriers
In the short term, we will see space being broken up with temporary dividers and partitions giving workers a sense of privacy and security. They’ll break up ancillary spaces to encourage smaller “huddles.” They’ll be used to promote privacy in an open floor plan. They come in a ton of different shapes, sizes and materials so they’re an excellent way to retrofit an environment.

Online is on target.

Encourage video conferencing and other collaborative meeting platforms
Keep workers connected and productive – across the building or across the globe. More online meetings & working-from-home. What does that have to do with the physical office space? A lot actually. Remember the whole “dedensifying conference rooms thing” from number three? It means less of us can gather in a room and jump on a call with our work-from-home collaborators. It means we may have to join the virtual meeting from wherever we are. It means offices will need to provide more locations for video calls for smaller groups of people. Less in closed conference rooms and more out in the open.

Don’t be so dense.















Rethinking Conference Rooms for a Less Dense “Shared Power” Experience
Currently, the CDC recommends we no longer gather in groups of ten or more. And there’s also the six feet rule that needs to be considered. A conference table that normally sat 8 people comfortable may only really work for 4 now. All of this means those large conference rooms that used to host big cross functional meetings may end up being used as storage for all of the chairs that have been removed from everywhere else.

TAKE IT OUTSIDE.


Capitalize on Outdoor Spaces for Added Real Estate and Healthy Distancing
The trend in working outside is not a new one. Millennials and GenZers have been demanding more outdoor spaces at the office for a while. Coming back to work after social distancing at home for months will surely heighten that demand. Being outdoors encourages physical well-being and mental well-being. And for many people, it’s been a huge factor in “keeping their sanity” during this challenging time.  Obviously working outside all day has its challenges – the weather, ergonomics, and the access to power too. But creating hardworking outdoor spaces for employees coming back to work will be a much needed breath of fresh air.

PRODUCTS TO POWER PRODUCTIVITY

As employers quickly improvise facilities and furnishings for returning employees, power may be easy to overlook, but it’s one of the most critical aspects of any successfully re-imagined workplace. We asked Dane (our Facility Manager again), what kind of role power distribution plays in getting spaces ready for back-to-work.

“Having multiple solutions for power has allowed us to reconfigure based on social distancing guidelines, knowing we had products that could support the new floor plan. When you only have to focus on the physical dimensions, knowing power solutions are in your back pocket to solve most issues, it allows you to be creative in problem solving.”

DESKTOP ACCESSORIES
There’s no easier way to turn one wall outlet into a bunch of places to plug in. And, our mounting options make it easy to add power to any table style. Mount it under the table, on the table’s edge, or as a freestanding unit. But just because they were designed for the desk doesn’t mean they’re not powerful in other places too. Remember those divider screens we talked about? You can easily add power to those too.



POWER FOR A WHOLE ROOM OF TABLES
Interlink IQ allows you to connect power to up to 8 tables with just one power cord. That’s one outlet – providing power to up to 8 tables. And it can be rearranged whenever and put back together however you want. It’s also great for providing power for a long table so coworkers can spread out at a shared table, without sharing power too.

POWER AWAY FROM THE WALL
Coming up with room for everyone, re-purposing furniture, following new rules and guidelines – it’s a lot. But arranging workstations around access to power outlets doesn’t have to be complicated too. There are plenty of ways to bring power to where you need it – no the other way around.

MORE OUTLETS WHEREVER YOU NEED THEM
If moving desks or seating up against the wall is the best way to give coworkers the distance they need, you may find having a few more outlets   a huge help. With 4-Trac, add up to 13 duplex receptacles without making any cuts in the wall. And there’s no need to involve an electrician either.

SPREAD OUT ACCESS TO POWER
Distributing power along the perimeter of a conference tables gives users their own access to charging so they aren’t reaching across the table or huddling close to shared outlets. Under-surface mounted power accessories are a great way to save valuable real estate on top of the table too. 2-Trac is a super low-profile DC power solution that easily offers multiple user’s their own place to charge up. Twine is a highly configurable branching cord solution that can definitely provide some distance.

OUTDOOR POWER
Outdoor Vesta is a completely battery powered charging unit that includes enough USB ports to share with the team. And, with waterproof USB ports, it’s safe to leave outside all day. Rain, snow, or shine – just bring it in to recharge now and then.

THE POWER OF PRIVACY
Creating physical barriers is an excellent way to break up a space and give coworkers some personal space, but they can also break up access to power. So, depending on what the space is being used for, it may be important to take that into consideration. Combining divider screen solutions and power distribution makes  it easy to retrofit privacy anywhere, without skipping a beat when it comes to productivity. Twine + Solo and Fence (coming soon) are great power partners for the privacy panels you’re sure to be using a lot of in the future.





At Byrne, we’re electrical experts so you don’t have to be. If you have any questions about power as you work through your new office layouts, just give us a call, or send us your new layout. We’re happy to help.

USB-C Charging Explained

, , ,


The biggest players in technology are moving toward adopting USB-C and the Power Delivery standard in their latest devices. That means we can start to charge all of our favorite tech (laptops, phones, speakers, smart watches, etcetera, etcetera) using the same cord, with the same connector. Type C comes with a ton of other benefits too, which we outlined in our last USB-C article. Check it out if you haven’t already.

USB-C can charge bigger devices than the USB we’re used to, and it charges faster too – about 70% faster actually.  While all of these advancements are great, understanding how Type C works for our unique devices can get a little confusing. We’ve put together some quick explanations and helpful hints, to help you get the most out of your USB-C charge.

Super Fast Charging & Power Delivery

Power Delivery (PD) is basically a fast charging protocol. It’s a standard that USB-C charging agrees to, so that everyone’s devices are compatible and have the same basic functionality. It’s kind of like how ‘Qi’ is the universal standard for wireless charging. It’s a common language that technology & chargers speak together and a common standard to which they’re tested.

Here’s what you should know about USB-C & Power Delivery:

  • With the launch of USB-C PD, charging power levels have increased up to a robust 100 Watts and 3 amps of power. And it’s this increase in power delivery that allows a USB-C cord to charge more power-demanding tech, like laptops, monitors, and even some printers.
  •  USB-C is bi-directional, so devices can either send or receive power. And power can be delivered at the same time a device is transmitting data, across the same connection—which means you can charge your phone with your laptop, or your laptop with your phone.
  • Because USB-C connectors were specifically designed with Power Delivery in mind, they’re able to carry this new higher wattage without being damaged or overheating.
  • USB-C with PD is smart. It delivers the power needed to charge a specific device as fast as possible without delivering too much, for optimal charging every time. How does it know? Well, the PD actually communicates with a device to determine how much power can be pulled from the charger, so it will never overpower or damage the unit.

What are some common devices that now use USB-C charging?

When it comes to USB-C Charging, how much power do you really need?

We know that USB-C with PD can deliver up to 100 Watts of power, but is understanding how much power a device needs actually important? Yes, sort of. You’ll want to check the specs on any PC before you buy, because not all USB-C ports are created equal. The good news is that, because USB-C is smart, you can’t overcharge your device. That means, plugging into a 60 Watt charger, when you only need 15 Watts, is completely fine. But, using too small of a charger, means you may not get as fast of a charge as you’re used to.

Obviously outliers exist, but this chart gives you a pretty good idea of the kind of wattage your device needs to get a good charge.

BYRNE IS ON BOARD

We understand that USB-C is positioned to be the new industry standard—which is why we already offer this universal interface in many of our products. But we also offer blended solutions that can charge your older devices too. The chart below can help you navigate which Type C charging outlet is right for you.

Whether you’re powering your home or office, a hospitality space or someplace in between, Byrne is committed to offering smart charging solutions that allow you to charge not only Type-C devices, but older devices as well. We’ve integrated USB-C into a variety of desktop and mobile power units, and it’s even available as an interchangeable “chiclet,” allowing you to customize nearly any Byrne power unit.

How do you know which charge is right for you?

Contact

THE POWER PUZZLE: REACHING MIDDLE GROUND

, ,

More and more, companies are embracing open concept work spaces—areas designed around optimizing human interaction and collaboration. And for many people, this kind of dynamic, synergistic work isn’t very likely if workers are tethered against the wall. Looking to create an active, team atmosphere where people and ideas thrive? You’re going to want power at the center—and in the center—of those spaces.

WHAT ARE MY OPTIONS?

The question reminds us a little of the old bear hunt story. But unlike the children’s tale, when it comes to confronting the challenge of power in the middle of the room, you can actually go over it, go under it, or go through it.

Trenching

With this first option, you don’t just go under the floor…you really go under the floor. Trenching is just what it sounds like—cutting a trench in the concrete to support required power and cable management. With this approach, you’re going to want some pros on your team beyond the folks handling the concrete work. An electrician will need to run the conduit and a networking expert should handle the data connections. Because of the physical commitment involved, the best fit for a trenched solution is usually a new build or a significant renovation project.



Raised Flooring

For this solution, we’re still on the floor—just not quite as far down. In a raised floor application, power is run between the actual floor and a product that sits on top. Those few inches gained with a raised floor translate into a myriad of power and cable management benefits. Power is free to be channeled where it’s needed and floor boxes installed in the floor provide easy access points for pulling cables through. However, raised flooring can become a tripping hazard issue by creating different levels of flooring in a space. But a raised floor solution can accommodate a lot of power—perfect for work spaces with a high demand for tech support, as well multipurpose work areas looking for greater power flexibility. Like trenching, this solution probably makes the most sense as part of a larger renovation project.



Ceiling Power Distribution

Now, we’re headed over…with power that runs through the ceiling. In this solution, ceiling tiles conceal power and other cables supported by trays that run from the wall to the middle of the room or forgo the ceiling tiles for an exposed, industrial style. Once there, power drops from the ceiling housed in a pole or similar structure. Please note that because of the additional distance traveled from point to point, extended cable lengths are often necessary. And because this application requires several structural considerations—including the need for a dropped ceiling product (unless you like the look of exposed cable hardware)—it’s usually best suited for new building projects.

Furniture Power Distribution

Our final solution involves running power through portable or stationery furnishings with outlet receptacles mounted on or in the furniture. Corded or hardwired—both are options—they simply require connection to a wall or floor power source. And flexibility isn’t only about how things are wired here. Running power through furnishings also means higher adaptability because power units can be easily moved as space demands change. Ultimately, furniture power distribution is a great fit for existing or remodeled spaces that’s aren’t looking for a more permanent, infrastructure-based solution.

THINKING IT OVER

Regardless of the approach chosen, power distribution in any workplace is an important consideration and asking the right questions is sure to mean fewer headaches (and wasted dollars) as you move forward. So, here are a few issues to keep in mind as you consider making your own workplace a more dynamic and collaborative “center” of attention:

  1. How much money and time are you prepared to invest?
  2. How much power do people using the space need? How much data?
  3. How involved is the project—will an electrician or other experts be needed?
  4. Are you paying attention to safety concerns?
    • Avoid any opportunities for tripping hazards
    • Be sure to check whether an electrical permit is required for your project
  1. Have you explored all the design and power options for your space?
    • Stay open to the possibilities!

AUTOMATION: FOR SPACES AS SMART AS THE PEOPLE WHO USE THEM

,

Building automation is a rising trend in today’s real estate marketplace. The automation of workplace functions allows a Facilities team to increase efficiency and track the use patterns of a space, as well as enables users to schedule events. These “smart building” systems use common communication protocols to talk to each other and share information with a central “brain.” A smart platform also allows integration with other building systems and the company’s IT infrastructure itself. Here, we’ll dive into what building automation really looks like, how it works and how your workplace can apply this technology to its best advantage.

AUTOMATION: HOW SMART IS SMART?

When people talk about a “smart building” what they’re referring to is the autonomous control of a facility—both distributed control and the building’s automation systems. Distributed control systems include things like monitors, mechanical functions, security, fire, lighting, HVAC and ventilation systems, either within a single building or across a campus. Building Automation System (BAS) functions are all about keeping an eye on things—maintaining climate within a specified range, lighting rooms based on occupancy schedules, monitoring performance and device failures and provide malfunction alarms accordingly.

It’s not hard to see how such automation systems reduce building energy and maintenance costs through pre-emptive maintenance and the quick detection of tech issues. In fact, smart energy management practices can often pay for themselves in a short period of time—and help companies tell a powerful sustainability story for customers, partners and employees alike.

QUICK FACTS



According to the Department of Energy, businesses consume 70% of the electricity load in the U.S. and waste 30% of the energy used per year.







By 2020, 19.5% of all buildings in the US will be automated, with 50 million connected devices.







Focusing on HVAC, lighting, and some types of electrical loads, mid-sized buildings implementing a proactive energy management program can expect savings from 10% to 25%.

TAKING CARE OF BUSINESS

Here are just a few ways in which automation can help today’s workplaces do what they do…better.

 SMART BUILDING ENERGY MANAGEMENT:

Within a business environment, some controls can and should be in the hands of the people who work there (individual level control), while others automatically kick in based on whether people are actually in the space or not (occupancy level control).

For example, with individual level control, an employee can engage the HVAC system in a conference room using an interface on their IP phone, if they happen to be working after office hours or on a holiday. At the Occupancy Level, unused equipment or appliances will power on and off automatically, without any needed user intervention—like automated blinds that adjust according to heat and light, or lighting that turns on according to movement within a space.

In either case, tracking real-time energy utilization for any building from a central location can help a Facilities team determine energy consumption patterns, design spaces more efficiently, and identify areas of improvement across departments. Better awareness of energy consumption levels and their sources can also enable companies to negotiate power contracts and better verify the billing info provided by those utility companies.

To learn about Byrne’s workplace energy management system, visit their Circuitrac website here.

ROOM RESERVATION:

Think of it as air traffic control for a company’s busy meeting areas. Employees can use a scheduling app on their phone to book a room. And even without an app, room sensors tied to the workspace reservation system can note movement and change the occupancy status within the system—effectively reserving the room to prevent employees from double booking. These same sensors can also tie into digital room signage and displays to indicate whether a room is available, reserved or occupied.

SPACE UTILIZATION:

Work space is expensive, so employers want to maximize its use wherever they can. In building automation, sensors record the use of a room, eliminating the need for employees to register that information themselves. Then space utilization reports can track when certain environments are being used, to help organizations make decisions about how to best allocate square footage—they can even help inform the creation of smarter workplace design layouts based on usage.

SO, HOW DOES IT ALL WORK?

In order for your building automation system to operate, you need five things:





SENSORS

The eyes of the building



Sensors measure information such as CO2 output, temperature, humidity, daylight or room occupancy and come in several types.

 MOTION SENSORS

These use passive infrared technology to detect heat and movement and are usually mounted to the ceiling or an area where the sensor has full range of vision within the room. Motion sensors deliver a 90-95% accuracy rate—accuracy may be reduced when people sit for long periods of time. While these sensors can detect if a person is utilizing a space, they can’t specify how many.

DESK SENSORS

These sensors utilize the same passive infrared technology as their motion-based partners and are designed to detect the presence of a person in a particular spot—desk, conference table, etc. As with the motion sensors, desk sensors may inaccurately capture data when people sit too long, which is why they tend to be more useful in gathering simple vacancy data.

VOLUME COUNT SENSORS

Unlike the sensors mentioned above, these are ideal for capturing the number of individuals entering and exiting a room. Mounted above the room’s doorways, companies can precisely track occupancy and analyze usage versus capacity. This data also helps improve office design by identifying where people are congregating and by providing data to adjust and improve wasted space.



SMART HUB (Controller):

The boss of the operation



The brains of your BAS (Business Automation System), these digital controllers receive input data, apply logic to that information (think algorithm, like Google does with their search data), then send out a command to other devices to adjust accordingly, based on the info gathered.





COMMUNICATION PROTOCOL

The channel your devices talk to each other on



The most commonly used communication channel, ZigBee radio communication protocol, is an openly available global communication standard that addresses the unique needs of low-power, low-cost wireless M2M (Machine-to-Machine) and IoT (Internet of Things) networks. In technical terms, it operates on an IEEE 802.15.4 physical radio specification and even on unlicensed frequency bands including 2.4 GHz, 900 MHz and 868 MHz. Zigbee offers a wireless range of 70m indoors/400m outdoors and uses military-grade AES 128 encryption for an exceptionally high level of information protection.



OUTPUT DEVICE

The IOT that controls your device



Once the controllers have gathered the data and determined what course of action your system should take, those commands are carried out by the system’s output devices. When the controller sends out a command, actuators and relays (the typical output devices) go into action—reducing or increasing the heat in a particular part of the building for example or dimming lights in unused areas.



DASHBOARD

How you view your data



Simply speaking, these are the screens or interfaces that work as a translator between a BAS system and the humans who operate it. This is where building data is reported (historical, consumable, run times, and system activity information) and can be used as a record of building operations. It also allows immediate diagnosis of a system without needing to be physically in front of the unit.



SMART JUST MAKES SENSE

Intelligent BMS systems integrate disparate BMS devices/networks onto a common network (IP) to enable unified automation and management, even though they may be manufactured by different vendors. In the future, we may even get to a single dashboard that can manage all BMS and Network/IT systems. Running a building should be a data-driven process. Analytics platforms like SkySpark, CopperTree, and others can pull in data from existing equipment and produce useful insights for facility managers to help make better operational decisions. Then the next logical step is to utilize that vast amount of operating data currently sitting unused by existing building control systems and turn it into actionable insights—so building operators can be free to focus on fixing problems, not out there searching to find them.

With today’s automated technologies, businesses are not simply in control of the function, safety and comfort of their buildings, they can operate those systems from a smarter position. One that not only increases employee satisfaction and informs better space allocation, but one that is sure to generate significant energy savings for years to come.



POWER: LET’S TAKE IT OUTSIDE

,

More than ever, people want to work where and how they work best. Thanks to the evolution of technology, that means taking advantage of outdoor spaces as well—but of course, powering up al fresco comes with its own challenges. The need for reliable outdoor power is not only increasing in the workplace, but in hospitality […]

Read more

PLANNING FOR POWER IN NEW WORKPLACE DESIGN

, , ,

In 2018, work spaces are entirely different than even 10 years ago. The days of “traditional” work spaces are quickly on dwindling, let alone the days of the “cubicle farm.” So what designs do matter for work spaces in 2018?

OPEN FLOOR PLANS

Open Floor Plans have been around for years, but we’re starting to see an increase in the use of this concept, moving from private offices and cubicles.

You read that right. Not only do these spaces not need “open door policies,” there aren’t even doors to close. Open floor plan offices encourage collaboration, shared work spaces, and everything that comes with them.

Designing work spaces has changed from a layout having just a few spaces within office buildings that are open concept to nearly the entire space as open floor plan. While the C-Suite may still have doors to close, the rest of the building likely will be sharing desks, outlets, and screens.

HOTELING AS A WORK SPACE

Working doesn’t have to be done at an assigned seat to be productive anymore. In fact, many people that come to the office take part in a trend called “Hoteling” or “Hot Desking”.

Hoteling doesn’t mean that you live at a hotel or even work in a hotel, instead it refers to using a scheduling system to reserve a desk for the day or a few hours. Hot Desking is similar, but deals with unassigned seating by a first come, first served basis.

Each of these concepts is moving us away from having an assigned or static desk and moving to an environment where you sit where you feel you’ll get your best work done. Heads down work could be in a space with more barriers and a quieter environment, collaboration could happen when your team decides to sit together for a day or two.

This surge in providing unassigned workspaces is already changing the face of many offices and can be seen in the rise of Co-Working Spaces.

STANDING WORKSPACES

Standing work desks are more than just a passing fad. Their sudden rise in popularity is linked to more than just health benefits. From a facility point of view this is saving valuable real estate or even allowing new workspaces to be deployed within an existing footprint.

Standing desks increase collaboration, focus, and productivity. You may have heard the phrase “sitting is the new smoking,” but you may not be familiar with all of the benefits of standing.

WHAT DOES THIS MEAN FOR YOU?

As new workers arrive in the office we need the workspaces to meet their needs not just for doing a task, but also meeting their social needs.  That means that our workspaces are changing and how we design them up makes a difference. The goal of a great workspace design is to provide the tools that someone will need, so that all they need to do is sit down, plug in and get to work.

With every day and the improvement technology tools at work, the way we work changes. And when the way we work changes, workspace design needs to change too. How is it affecting you? Let us know in the comments of this blog.

WHAT IS THE DIFFERENCE BETWEEN COWORKING SPACES AND MAKERSPACES?

,

Welcome to the wonderful world of being able to work wherever you want. Well, almost.

Coworking spaces and Makerspaces have been on the rise since the integration of technology into the workplace. While both spaces are slightly different and used for different types of work, they both help usher in a new era of developing the freedom to work away from your specific office.

Whether to make working while traveling easier or to give remote workers a home base (other than their dining room table), both spaces are unique in that they foster a work community outside of a company’s four walls.

COWORKING SPACES AND WHY THEY’RE IMPORTANT TRENDS FOR DESIGNERS AND MARKETERS

In 2005-era San Francisco, Brad Neuberg realized he could create his own coworkers. By attending networking events and slowly gathering a group of like-minded individuals, Brad discovered that all it took was a shared space and passion for people to connect. They didn’t need to be employed by the same company, and in fact they learned much more from each other than from their companies. And with this idea, coworking spaces were invented.

This incredible trend has continued (and swept the world with it) for 13 years now.

Coworking spaces have completely changed the way employers view the 9 to 5 landscape. Gone are the days having to sit in front of a screen for 8 hours a day in an office (heaven forbid in a cubicle…). This new style of space has created a new culture around working.

Designers focused on developing and improving coworking spaces can’t ignore the high level of technology integration. The ability to connect PC or Mac to any outlet and any other gadget is critical.

The importance of coworking spaces is just that – they allow collaboration and they work. It’s the seamless integrations that often make the space. Add in a banging modern facade and you have the total package in a coworking space.

MAKERSPACES AND WHY THEY’RE IMPORTANT FOR DESIGNERS AND MARKETERS

Makerspaces are directly engineered for prototypers. In fact, they might even be better known by their nickname: hackerspaces.

These spaces are an entirely new realm outside of coworking spaces. They’re developed in an effort to foster a community that likes to build, invent, create, and learn. Rather than creating a networking space that encourages like-minded computer dwellers to collaborate, Makerspaces encourage the handcrafted to gather together.

Typically outfitted with technology such as 3D printers, models, software, and other electronics that enhance crafting, Makerspaces are still a rare find. And their rarity makes them that much more marketable.

It’s ever-important for designers to keep in mind that while Makerspaces are still in their infancy, they will only explode from here. Discovering the right technology to integrate, layouts to develop, and freedom to collaborate through open floor plans are imperative.

THE DIFFERENCE BETWEEN USB 2.0, USB 3.0 AND USB 4.0

, ,

The Universal Serial Bus (USB) has quickly become an expected technology included in any new tech hardware. From smartphone chargers to flash drives and printer to computer connections. But what is the difference between the two most common USB versions, USB 2.0, USB 3.0 and USB 4.0?

5 KEY DIFFERENCES BETWEEN USB 2.0, USB 3.0 AND BEYOND

USB 2.0 was released in 2000 whereas USB 3.0 was released in 2008. In those 8 years, 5 major innovations improved the usage of USB 3.0. Coming in 2019, USB 4.0 will be released to address higher data transfer rates.







Transfer Rates (Speed)



USB 2.0 has a transfer rate of 480 Megabits per second (Mbps). Its counterpart USB 3.0 has a transfer rate of 10x that, offering a transfer rate of 5 Gigabits per second (Gbps). More recently, USB 3.2 offers a transfer rate of 20 Gbps and in 2019, we can expect the ratification of USB 4.0, which will offer 40 Gbps.  These transfer rates allow quicker uploads of data.



Physical Changes



In order to offer an increase in the transfer rate, the USB Type-A/B connector for USB 3.0 and higher requires more pins than USB 2.0, increasing from 4 to 10. To accommodate the physical updates, USB 3.0 required the design of new USB Type-A/B connectors.  Additionally, the arrival of the USB Type-C connector has 24 pins and allows for inverted insertion.





Bandwidth



USB 2.0 offers one-way communication between devices. This means that it can only handle data transfers one direction at a time. With USB 3.0, they contain two unidirectional paths, allowing them to maintain transfers in both directions at the same time. While the USB-C connector adds two more data paths for a total of four.  These are key innovations for improving data transfer load times and improving efficiency.



Power



While simultaneously sending data, USB 2.0 provides a maximum of 500 mA when charging devices. USB 3.0 offers up to 900 mA – cutting charging time nearly in half while sending data.  The categorizing of USB power has evolved and new standards have been released for power delivery.  Depending on the connector and wire type, up to 5A at 20V or 100W can be delivered to a device needing a charge.



Compatibility



The USB Implementers Forum (USB-IF) maintains that their revisions are always backward compatible.  This means that USB 2.0 devices are compatible with USB 3.0 – though only at USB 2.0 speeds.

If you are looking to learn even more about the USB versions available, be sure to check out our USB 101 blog.



USB 101: THE DIFFERENT VERSIONS AND CAPABILITIES OF USB

,

The Universal Serial Bus was originally developed to be an industry standard connection between communications, computers, and other devices. Dubbed the USB, this technology quickly replaced previous standards that hadn’t been regulated across devices. It became the gold standard, the Lingua Franca of the technological boom.

5 MAIN USB VERSIONS AND WHAT THEY DELIVER

There are dozens of different types of USBs, from 1.0-4.0, A-C, and even minis – and it’s tough to keep track of which ones perform what.

USB 1.0 Capabilities

USB 1.0 was originally designed in an effort to streamline connection between all devices. After arriving on the scene in 1996, USB 1.0 became the go-to standard between brands, technologies, and devices.

USB 2.0 Capabilities

After USB 1.0 took off in popularity, USB 2.0 set out to increase speed for connecting, charging, and sharing. USB 2.0 went through several iterations over a multiple year span, becoming a critical innovation from 2000-2010 that ushered in a new age of expected speed and accuracy for syncing devices, charging rapidly, and sharing downloads and uploads seamlessly.

USB 3.0 Capabilities

USB 3.0 was developed basically to shame anyone who thought 2.0 was truly an upgrade (kind of). It introduced the USB “SuperSpeed” capability, as well as improving data transfer and charging speeds. USB 3.0 ports are denoted with a blue color code (or the super sweet SS initials).

 USB 4.0 Capabilities

USB 4.0 was developed to improve upon data transfer rates up to 40 Gbps and interoperability with Thunderbolt.  This capability will available on the USB-C connector and cable.

USB Type-C Capabilities

USB Type-C is backwards compatible with USB 3.0 and 2.0, eliminating the compatibility with Type-A ports. Almost any device that supports USB 3.1 use USB-C port. Both ends of the USB cable are the same which allows a device to be connected with reversible plug orientation, so you never have to worry about plugging in your device the wrong way. USB Type-C delivers more power which gives the opportunity to charge larger electronics, such as laptops.

WHY DO THE DIFFERENT USB VERSIONS MATTER?

Each USB version delivers different speeds and works with different ports.

It’s important to understand which USB versions work best on which power levels. In order to incorporate USB ports into designing spaces and furniture, it is critical to know what USB version will fit most efficiently. Whether you are looking for a fast charge to keep people moving along, a trickle charge hoping they’ll stick around longer, or the ability to sync and share between other devices like printers and computers, you’ll need to know each capacity.

An easy fallback is to assume that USB 2.0 ports will work well when incorporating into furniture. While USB 3.0 is even better, USB 2.0 is still internationally the most compatible option. In theory, USB 3.0 was developed to work on 2.0 ports and for 3.0 ports to also accept 2.0 charging and data transfers.

As always, the supplier of your tech will know best – don’t be afraid to ask questions. After all, they’re there to help you succeed. Check out Byrne’s variety of USB solutions to best meet your power and data needs.

WHAT ARE THE RISKS OF NON UL APPROVED PRODUCTS IN YOUR WORKSPACE?

,

Outfitting an entire office space can seem daunting at first.

Confronting a budget in this scenario is particularly complicated. And in times like this, it can be easy to want to find a way to cut a few corners and save some cost.

But finding cheaper (emphasis on the cheaper) products to outfit the new space is not the answer. UL approved products offer more than just efficiency – they offer safety.

WHY ARE NON-UL APPROVED PRODUCTS RISKY?

There is a very good reason why Underwriters Laboratories came to exist. In a world of ever-expanding products, inventions, and evolution, this organization took upon itself to ensure that there is a set of safety standards to protect the users.

With an influx of manufacturers (and a need to keep costs low), it has become increasingly more important to abide by the vigilance of UL. Products that sell for lower prices must be made with lower quality – and it is these products that are less safe. The use of inferior products creates hazards for workplaces housing expensive equipment and easily ignitable material. The cost savings of purchasing non-UL material doesn’t match the risk imposed on the company, equipment and employees.

UL discovered what materials, layouts, and other design elements encouraged electrical safety in particular. Their standards protect users from potential fires, electrical shock, and personal injury hazards. Whether the products are office furniture, additional power or charging accessories, UL set a code of standards for various levels of safety based on their testing.

UL VERSUS ETL

You may see companies carrying a UL listing, an ETL listing, or both. Here’s what you need to know to distinguish the two certifications.

UL: Underwriters Laboratories, or simply known as UL, writes safety standards and tests products to ensure they meet the requirements of the written safety standards. In order for a product to be UL certified, a product sample must be tested and complete all safety regulations put into place by the UL.

ETL: Electrical Testing Laboratories (ETL) includes the safety testing for a variety of electronic components and their associating products. ETL differs from UL because ETL doesn’t test products according to their own set of standards. Products undergoing ETL testing are held to published standards of safety such as ASME, ASTM as well as UL.

For more information and to discover specific details surrounding UL listings, browse the full catalog here. Learn more about UL Listed vs UL Recognized products as well in this helpful blog.





Bob’s Brain is a dedicated service and guide for technical learning in power and data.

WE’RE THE ELECTRICAL EXPERTS, SO YOU DON’T HAVE TO BE.

powered by byrne

Subscribe To Our Newsletter
